M2000 TS Description
1-26 Manual # 42-02-1P28 A3
Table 1.14 Status Information
Topic Description
CPU-Bus-Com Status Conditions affecting microprocessor communication with activity indicator
Monitoring Tools Reset Xport, Default Password, TFTP Status
Can Bus Viewer View CAN bus device IDs and related messaging activity.
Version Information Software version information
Other Car Settings Second car settings display for duplex operation, Sabbath Mode, etc.
Address Diagnostics Access selected processor register contents via address entry. Technician
assisted troubleshooting.
Table 1.15 Statistics
Topic Description
Maintenance Statistics Statistics pertinent to system maintenance
Hourly Statistics Statistics for the last 24 hours of operation, per hour (car and hall calls)
Hall Bus Inventory Inventory and test hall call nodes and indicators
Table 1.16 Scope
Topic Description
View Scope Select and track four system signals in near real time, from:
Landing System Switches, slowdowns, door zones
System Inputs Dedicated inputs
Programmed Inputs Assignable inputs
System Outputs Dedicated outputs
Programmed Outputs Assignable outputs
