M100 Tow Tractor Manual No. 46052
PAGE 37
CHAPTER 2 MAINTENANCE
Always set the parking brake when parking the machine. The
transmission does not have an internal parking lock and failure to apply the
parking brake could allow unexpected movement resulting in crushing injury
or death.
4. Remove 21 washer-head screws retaining the oil pan to the transmission
housing. Discard the pan gasket and clean the pan with mineral spirits.
for this and all remaining steps).
6. Clean or replace the governor oil screen by removing the governor feed
tube. This tube and the remaining two tubes are held in place by the control
valve body.
Tighten the screw to 10-15 lb ft.
oil pan lip. Do not seal gasket with any substance other than transmission
11 . Carefully attach oil pan to transmission by hand with four 5/16-18
washer-head screws. Thread one screw into each corner. Do not allow
dirt or debris to enter transmission.
12 . Install the remaining 17 screws by hand, carefully threading them through
the gasket and into the transmission. Bottom all screws before tightening.
13 . Tighten all 21 washer-head screws evenly to 10-15 lb ft. Monitor gasket
NOTE: The oil pan bolts must maintain a minimum of 5 lb ft of torque after the
oil pan gasket has taken a set.
ft. Install the drain plug and o-ring. Tighten the plug to 15-20 lb ft.
the driver’s side inside frame plate near the back of the transmission.
Servicing 9.00 Qts.
Rebuild 15.00 Qts
17 . Check oil level.
1 SERVICING
APRIL 15, 2012
