NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 35
CHAPTER 4 REPAIR PARTS
JANUARY 31, 2007
4 ILLUSTRATED PARTS LIST
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
13-
Parking Brake, Allison AT545 Ref
5
NW033074 Cam (73342), 2005754 1
6
Pin, Clevis (73342), 121741 2
7
Pin, Cotter (73342), 103372 2
8
Clevis, Rod End (73342), 681664 1
9
Clevis, Adj Rod End (73342), 144242 1
10
Bolt, 3/8-16x2.75 (73342), 9442250 1
11
Washer (73342), 2374941 1
12
Spacer, Sleeve (73342), 611380 1
13
NW034469 Crank, Bell, Park Brk (73342), 701314 1
14
Bolt, 7/16-14x1.25 (73342), 9441893 2
15
Washer, Flat 7/16 (73342), 2436164 2
16
NW034470 Plate, Park Brake, Brkt (73342), 15647373 1
17
Washer, M10 Flat (73342), 15531204 1
18
Nut, 3/8-16 (73342), 9422297 1
24
F016825 Hex Nut, 1/2-13 4
27
308743 Sup port Plate Asm 1
29
NW033073 Brake - Transmission Parking (05WC5), 4153501 Ref
30
Spring, Red (05WC5), 308664
31
Assembly, Shoe & Lining-one shoe (05WC5),
4152204
2
32
Spring, Brown (05WC5), 3203360 1
33
Spring, Green (05WC5), 308665 1
35
NW036316 HHCS, 1/2-13 x 1-3/4 4
36
NW033068 Drive Shaft Flange 1
38
Comm Hex Nut, Slotted, 1/2-13 1
39
NW022072 Brake Drum 1
