M100 Tow Tractor Manual No. 46052
PAGE 41
CHAPTER 4 REPAIR PARTS
4 ILLUSTRATED PARTS LIST
NOVEMBER 02, 2015
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
16-
Frame Solid Ref
1
Frame Weldment Ref
46856-8 Frame Weldment, 100, Wide Spring, 124” O Ref
46856-2 Frame Weldment, 100, Wide Spring, 124” O Ref
46856-7 Frame Weldment, 100, Wide Spring, 124” O Ref
2
46762 Support Wldmt,Hood,100,Zenith 1
45937 Support Wldmt,Hood,100,Cummins 4B4.5 (Used on
46400)
1
40441 Hood Support M 1
44185 Hood Support, Std Drag Link Steering N 1
44188 Hood Support, Optional Hyd. Steering N 1
F102416 Rubber Seal (Austin), 3-10609 A/R
41394 Counterweight 8
37506 Insulation, 1" Foam (with cab option) Ref
3
Counterweight Stack (see gure 18)
4
38851 Front Bumper, Optional Rubber 1
5
42342 Opt, Rubber Bumper, Full Front Ref
6
41241 Plate, Rubber Bumper 2
7
39098 Bumper, Rubber, 2 x 9 2
8
41242 Plate, Rubber Bumper 1
9
38038 Bumper, Rubber, 42” Long 1
10
Comm HHCS, 3/8-16 x 1.25 8
11
Comm Flat Washer, 3/8 8
12
Comm Lock Washer, 3/8 8
13
Comm Hex Nut, 3/8-16 1
14
51373 Skidplate, Trans, B3.3/C6 O 1
NS
41246 FHSHCS, 1/2-13x1.5 4
NS
41238 Washer, 1/2 Shakeproof 4
NS
NW036316 HHCS, 1/2-13x1.75, Gr. 8 4
NS
F015973 Washer, 1/2 Lock 4
