NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 43
CHAPTER 4 REPAIR PARTS
4 ILLUSTRATED PARTS LIST
NOVEMBER 02, 2015
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E Units
Per
Assy
17-
44244 Sheet Metal, Chassis Assembly Ref
46480 Chassis Assy, M100, 28” Wide F/R O
Ref
1
41652 Rear Body, 100W/120” frame, Std 1
41910 Rear Body, 100, 11” Tub w/ Cutout 1
41281 Rear Body, Std Cab 1
41825 Rear Body, 11” Cab 1
41946 Rear Body w/ Cab Only 1
42314 Rear Body w/Cargo & Grd Carrier 1
41808 Rear Body w/ Passenger Seat 1
41956 Rear Body w/ Suspension Seat & Passenger Seat 1
42152 Rear Body w/ Suspension Seat & Cab 1
2
38038 Bumper, Rubber, 2 x 9 x 14" 1
41242 Plate, Mounting, Bumper, Rubber 1
3
44269 Panel Assy, Side 1
37405 Panel, RH, Engine Side 1
41507 Panel, LH, Engine Side 1
44270 Panel Assy, Side, Duetz 1
37405 Panel, RH, Engine Side 1
41235 Panel, LH, Engine Side, Deutz 1
46499 Panel Assy,Side,M100,ZTH,124" 1
46502 Panel,Side,LH,M100,124" 1
46780 Panel,Side,RH,M100,Zenith 1
46989 Panel Assy,Side,M100,(Used on 46765)
46008 Panel,Side,RH,M100
46860 Panel,Side,LH,M100
F101603 Rubber Trim (Austin), SD 1250 12”
Comm THMS, 3/8-16 x 1.00 2
Comm THMS, 3/8-16 x 1r, .25 2
Comm Flat Washer, 3/8 2
Comm Lock Washer, 3/8 4
Comm Hex Nut, 3/8-16 4
4
37403 Hood Assembly F 1
46015 Hood Wldmnt, Cummins QSB4.5 & Zenith E 1
5
37604 Hood Hinge 1
NW034546 THMS, 1/4-20 x 0.75 10
Comm Lock Washer, 1/4 10
Comm Flat Washer, 1/4 10
Comm Hex Nut, 1/4-20 10
6
NW034658 Hood Handle (Black Austin), 2786 1/2G 2
Comm RHMS, #10-32 x 0.50 4
Comm Lock Washer, #10 4
Comm Hex Nut, #10-32 4
7
NW022814 Latch Assembly, Flex Draw (94222), 37-10-086-10 2
40290 PHMS, #10-32 x 0.50 8
Comm Lock Washer, #10 8
Comm Hex Nut, #10-32 8
8
42539 Shock Assembly, Gas,90 Psi Ref
46630 Shock Assembly, Gas, 120 Psi Ref
NW035891 Gas Shock Cylinder, 90 Psi 2
NW035713 Gas Shock Cylinder, 120 Psi 2
NW035714
Ball Stud
4
NW035715 Clip 4
