NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 153
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
60-
Grp, M100, Air Cond, Firewall, DC Ref
1
38353 Air Conditioner, Firewall Mnt 1
2
206640 AC Condenser, 2000 1
3
42618 Bracket Wldmnt, AC Pump Mntg 1
4
41482 Compressor, Air Cond, Rear Port 1
5
38768 Receiver Dryer, Air Cond 1
6
38769 Bracket, Receiver Dryer, Air Cond 1
7
42993 Strap, A/C Compressor, M200 2
8
F101156 Clamp, Hose, #12, .69-1.25 6
9
41410 Hose Assy, AC, #6, 24.0”, EL/EL 1
13
NW021634 Hose 0.62 ID x 0.90 OD 88”
14
38825 Switch, Binary, Air Cond 1
15
NW022828 Cable Assy, Chole, JG40PT15 1
16
F101627 Knob, Cole Hersey 1
17
42814 Decal, Heater Temp Control 1
18
43502 Pulley, Fan Hub, Cummins 1
19
F101903 V-Belt 7450 1
20
44161 Plate, A/C Switch Mnt 1
21
44162 Cover, A/C Switch 1
22
Switch Assembly (Supplied w/Air Conditioner) 1
23
Filter (Supplied w/Air Conditioner) 1
24
44772 Mount, Condenser/Cooler 2
25
417603 Spacer, Condenser/Cooler .38T 4
26
417604 Spacer, Condenser/Cooler .25T 2
27
44629 Support, Rear Hood, Firewall AC 1
28
NW034742 Insulation, Firewall 1
29
NW032352 Ftg, 08MP-10H 2
30
3.0746 Ftg, Ell, 08FP-08FP90 Galv 1
31
3.0746 Ftg, N, 08MP, Close Galv 1
32
9.0027 Hose, .62, Heater 88”
33
45653 HHCS, 3/8-16 x 5 1/4, Gr8 1
41631 FW, 3/8 1
37744 Nut, Nylock, 3/8-16 1
34
F101448 HHCS, 3/8-16 x 1 1/2 2
41631 FW, 3/8 2
37744 Nut, Nylock, 3/8-16 2
35
F100376 HHCS, 3/8-16 x 1 3/4 2
41631 FW, 3/8 2
37744 Nut, Nylock, 3/8-16 2
36
45498 M10 x 1.5 x 30mm Gr10.9 3
NS
38824 Harness, Wire, Air Conditioner 1
JANUARY 31, 2007
4 ILLUSTRATED PARTS LIST
