NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 155
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard
Part No.
Vendor
Part No.
Nomenclature E Units
Per
Assy
60A-
38353 Air Cond, Firewall Mount x Ref
1
38353-7 Housing Assy x 1
2
38353-6 Filter, A/C Unit x 1
3
38353-8 Cover, Assy Top x 1
4
38353-9 Heater Core Assy x 1
5
38353-10 Evaporator Assy x 1
6
38353-11 Expansion Valve x 1
7
38353-12 Spring Clip x 1
8
38353-13 Gasket Core x 1
9
38353-14 Thermostat x 1
10
38353-15 Motor Blower Assy x 1
12
38353-16 Brkt, Blower Assy x 1
13
38353-17 Attch Strip Assy x 1
14
38353-1 Motor, Evaporator Fan x 1
16
38353-2 Housing Blower Motor x 1
17
38353-18 Blower Wheel x 2
18
38353-19 Plenum Assy x 1
19
38353-20 Louver Assy x 3
20
38353-21 Louver x 2
24
38353-22 Relay x 1
26
38353-23 Swivel Fitting Assy x 2
27
38353-24 Control Panel Assy A/C Only x 1
28
38353-25 Control Panel Assy A/C-Heat x 1
29
38353-3 Switch, Fan Speed A/C (inc. in 27-28) x 1
30
38353-4 Switch, A/C Mode (inc. in 27-28) x 1
31
38353-5 Switch, Heat Mode (inc. in 27-28) x 1
4 ILLUSTRATED PARTS LIST
JUNE 01, 2016
