NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 317
CHAPTER 4 REPAIR PARTS
Fig.-
Item
NMC
Wollard Part No.
Nomenclature E󰀨 Units
PerAssy
132-
46200-1 Engine/Transmission, Perkins 1104-44 T2/C6 Ref
45094 Pump Assy,Hyd,C1104/C6 (Also See Fig 22)
1
44827 Engine, Perkins 1104C-44, C6, T2 1
2
38733 Fitting, Pipe, Nipple, 1/8-27 w/Hex 1
3
3.1820 Fitting, Pipe, Tee, 1/8 NPT 1
4
F101526 Sender, Temp 1
5
F101527 Sender, Oil Pressure (V00542) 02025-00 1
6
NW021649 Switch, Pressure (13445) 8647 1
13
43258 Pivot Weldment, PS Pump 1
F100196 HHCS, 3/8-24 x 1.25 2
F009665 Lockwasher, 3/8 2
14
NW033586 Valve, Relief, PS, 1100-1200 PSI 1
15
F102526 Pump, Power Steering 1
F103926 HHCS, M10 x 1.5 x 25mm DN 933 2
F018486 Lock Washer, 7/16 3
16
38334 Plate, Adjuster, PS Pump 1
17
NW023994 Pulley, Steering Pump (1HS72) 3830967 1
18
37678 Fan, 16" Puller (V00547) 412505 1
19
44941 Adjuster, Power Steer Pump, 1104 1
20
NW010518FB Strap, Ground 1
21
F100780 Reducer, Bushing, 1/2 NPT to 1/8 1
22
45093 Belt V, G 7355, 3/8 x 36 1/4 7355 1
27
40480 Spacer, PS Pump 1
28
NW031646 HHCS, 10mm x 30mm GR 8 2
29
38321 HHCS, M16 x 40mm 2
30
F103926 HHCS, M10 x 1.5 x 20mm DN 933 2
37
NW03461 Socket Head Bolt 1
39
F104348 HHCS, 12mm x 1.75 12
40
F100405 HHCS, 5/8-11 x 4, GR5 2
41
204714 FW, 5/8 SAE, Hard 2
42
F018701 HHCS, 1/2 x 1-3/4 6
43
F100064 Washer, 1/2 Flat 6
44
F015973 Washer, 1/2 Lock 14
45
F016825 Nut 1/2-13 Hex 6
46
37535 FW, .66 ID, 3.12 OD, .19 thk 4
47
3.0391 Nut, Hex, 5/8-11 Lock, Esna 2
65
44631 Engine Mount, Perkins RH 1
66
44670 Engine Mount, Perkins LH 1
67
44514 Isolator 2
68
44634 Mount Wldmt, M60, Engine-Frame 2
69
42031-20 Tube, Dipstick 4126X091 1
85
44859 Brkt Wldmnt, Fuel Filter, P1104 1
86
204783 Spacer, Brake Lever, P1104 1
87
44940 Angle, Dipstick Mnt, C6 1
88
44888 Plate, Mnt, fuel Filter, P1104 1
89
44942 Spacer, Power Steer Pump, 1104 1
90
400906 Spacer, Cut, 4009, 1.00 1
NS
400904 Spacer, Cut, 1.60 1
NS
39981 Brkt, Dipstick 1
4 ILLUSTRATED PARTS LIST
JANUARY 31, 2009
