NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
PAGE 389
CHAPTER 4 REPAIR PARTS
MAY 15, 2016
4 ILLUSTRATED PARTS LIST
Fig.-
Item
NMC
Wollard
Part No.
Nomenclature E󰀨 Units
Per
Assy
164-
53475-1 Eng,Trans,Mntg, Kubota WG3800/GM Q Ref
1
53455 Engine, Kubota WG3800, SAE3/11.5 1
2
52965 Transmission, GM, 4L70 1
3
53454 Adapter, Flywheel Housing 1
4
52968 Kit, Park Brake, GM Trans 1
5
53130 HHCS, M12 x 1.5 x 35mm 8
6
53462 Adapter, Flywheel 1
7
53476 SHCS, 3/8-16 x 1 9
8
37674 Isolator, Rubber, Engine 2
9
53515 Support Wldmnt, Trans 1
10
53493 Driveshaft, 20.25-22.2 1
11
52228 Mount, Trans, GM 1
12
NW034224 Yoke, Flange 1
13
53597 Mnt, TCU, M100GK 1
14
53480 Mnt, Wldmnt, Eng/Frame 1
15
53477 Mnt Wldmnt, LH 1
16
53478 Mnt Wldmnt, RH 1
17
42040 Snubber, Leaf Spring 2
