NMC-WOLLARD 2021Truax Blvd., Eau Claire, WI 54703, Phone (715) 835-3151, Fax (715) 835-6625
M100 Tow Tractor Manual No. 46052
DECEMBER 15, 2013
PAGE 187
CHAPTER 5 MAUFACTURER’S INFORMATION
© 2013 General Motors. All rights reserved
Case Extension Assembly Seal Replacement
Removal Procedure
Raise and suitably support the vehicle as required. Refer to manufacturer’s
instructions regarding Lifting and Jacking the Vehicle.
Support the transmission with a transmission jack.
Remove transmission mount.
Transmission Mount Replacement.
Place a drain pan under the vehicle.
Remove the propeller shaft.
Remove the 2ௗbrake caliper pin bolts (1).
Warning: Avoid taking the following actions when you service wheel brake parts:
GM 4L70 TRANSMISSION
