EV Series Automated Dispensing Systems
79
Appendix A, Command Function Reference
(continued)
Line Speed
Click Function
Sets the speed (in mm/s) at which the dispensing tip travels at the location in the program where this command
is inserted, thus overriding the default system line speed setting.
Line Start
Click Function
Registers the current XYZ location as a Line Start point for line dispensing.
NOTE: The correct sequence of commands for a line is as follows: (1) Line Start, (2) Line Passing, (3) Line End.
Loop Address
Click Function
Double-click
address and
select from
drop-down
menu
Loops the program back to a specic Address (A) or Label for the number of times set for Count.
Parameter Description
Address The Address (A) or Label number the program jumps to. The jump-to Address (A) or Label must
occur before the current address.
Count The number of times to execute the loop.
Mark Adjust
Click Function
Double-click
address and
select from
drop-down
menu
When used in tandem with the Find Mark command, causes the system to search for the mark specied in the
No. (number) eld of the Find Mark command. When the system nds the mark, it checks the XY position of the
workpiece and adjusts the dispensing path accordingly.
Multi Needle
Click Function
Double-click
address and
select from
drop-down
menu
In multiple dispenser installations, species the dispenser (called Needle Number) to execute the commands that
follow this command. Currently up to ve dispensers can be installed, so the Needle Number parameter can be
1–5.
NOTE: For this function to operate correctly, the additional dispensers must be installed and set up. Refer to
“Appendix D, Multi-Needle Setup and Use” on page 92.
Output
Click Function
Causes the program to send an output signal from the specied output port.
Parameter Description
Port(1~8) Sets the output port number.
0 Off, 1 On Turns the output OFF or ON.
