P SENSOR C1
10
bar
P SENSOR C5
0
bar
P SENSOR C2
0
P SENSOR C6
0
P SENSOR C3
0
P SENSOR C7
0
P SENSOR C4
0
P SENSOR C8
0
Overpressure fault
Overpressure warning
Underpressure warning
bar
bar
bar
P SENSOR C1
Operation
4-69
P/N 7105144G
2008 Nordson Corporation
VersaBlue_NW
NOTE: The value for the overpressure warning can not be greater than the
value for the overpressure fault.
NOTE: Only with Speed control (pressure display): The value for the
overpressure warning/fault can not be less than the value for the
underpressure warning.
Overpressure fault: 15 bar (1500 kPa / 218 psi)
Overpressure warning: 10 bar (1000 kPa / 145 psi)
Underpressure warning: 0 bar (0 kPa / 0 psi)
Pressure Sensor C
Unlike pressure sensors A and B, the pressure sensors C are not assigned
to a motor. For this reason, the operator is shown a screen with an overview
of all sensors and their actual pressure values.
Example Fig. 4-99: There is only one pressure sensor C1.
Fig. 4-99
Only in Conjunction with ACM
The key To next screen appears if at least one of the two ACMs is available.
Touch the key to move to two more screens. All of the other 24 temperature
channels are shown there.
NOTE: CAN bus sensors can only be assigned up to sensor C8.
CAUTION: Analog and CAN bus pressure sensors have a different
pressure range end value. When in doubt, refer to the ID plate of the
respective sensor.
P SENSOR C1
To the pressure alarm parameters
NOTE: The values for warnings and faults are absolute values in Speed
control mode with the option Pressure display (Fig. 4-96). With the option
Pressure control, the values are differential values for sensors A and B
(Fig. 4-97)and absolute values for the sensors C (Fig. 4-96).
Fig. 4-100
To Next Page
