167
• Apply a coin and tighten until secure. The outer surface of
the Battery cover should be flush with the outer surface of
the housing (Fig. 173).
TMT INSTALLATION ON REGULATOR
To install the TMT (Transmitter) on the Regulator First Stage:
• Lightly lubricate the o-ring and threads of the TMT fitting
with a halo carbon based lubricant such as Christo-Lube
MCG111.
• Thread the TMT clockwise by hand into the Regulator's HP
port (Fig. 174) and tighten until secure with a 5/8" open
end wrench.
• Attach the First Stage to a full Scuba Tank and pressurize by
slowly opening the tank valve, listening for any indication
of air leaking around the fitting.
• If air leakage is present, DO NOT use, take the complete
Regulator Assembly to an Authorized Oceanic Dealer for
inspection and service.
Fig.174-INSTALLINGTMT
Fig.173-BATTERYCOVER
