6. Troubleshooting procedure
372
Open Cover
PaperJam
Front Cover
Remedy when the above messages are displayed
(1) Insert your finger into the recess on the right side of the printer and pull the front
cover open lever to open the front cover forward.
(2) Remove the jammed paper gently.
If an edge of jammed paper can be seen
2. Check for jammed paper inside the printer. If jammed paper remains, remove
it.
3. Close the rear cover.
If you cannot find the jammed paper
1. Open the rear cover by pulling the lock lever on the back side of the printer
toward you.
Lock lever
Rear cover
Front cover
Front cover open lever
