6. Troubleshooting procedure
381
Open Cover
PaperJam
Top Cover
368
Open Cover
Paper Remain
Top Cover
Remedy when the above messages are displayed
(1) Insert your finger into the recess on the right side of the printer and pull the front
cover open lever to open the front cover forward.
(2) Open the top cover.
(3) Remove ID unit and place it on new paper etc. on a flat surface.
(4) Cover the removed ID unit with paper so that it will not exposed to light.
(5) Pull out the jammed paper gently toward the inside of the printer (in the direction
of the arrow) if an edge of jammed paper can be seen on the back side of the
registration guide.
Front cover
Front cover open lever
To p cover
ID unit
