6. Troubleshooting procedure
(7) Pull out the jammed paper gently in the direction of the arrow if an edge of jammed
paper can be seen on the front side.
(6) Open the registration guide in the direction of the arrow. (9) Pull out the jammed paper gently while tilting the release levers (6) on the fuser unit
forward if an edge of jammed paper cannot be seen.
If an edge of jammed paper still remains inside the unit, pull out the jammed paper
gently toward the inside of the printer.
(10) Return the ID unit into the printer carefully.
(11) Close the top cover.
(12) Close the front cover.
Note! Cannot close the front cover securely if the top cover is not closed.
Registration guide
(8) Pull out the jammed paper gently in the direction of the arrow if an edge of jammed
paper can be seen on the back side.
