Oki B721 Maintenance Manual

Oki Data CONFIDENTIAL
45487001TH Rev.1
6-45 /
6. Troubleshooting procedure
(6) Hold the fuser unit handle and lift the fuser unit out of the printer.
Possible to get burned.
Do not touch the fuser unit. It is hot.
(7) Tilt the release lever on the fuser unit forward, and be sure to pull out the jammed
paper forward gently.
(8) Hold the fuser unit handle and return the fuser unit into its original position.
(9) Return the ID unit into the printer carefully.
Release lever
Fuser unit
(10) Close the top cover.
(11) Close the front cover.
Note! Cannot close the front cover securely if the top cover is not closed.
Fuser unit

Oki B721 Specifications

General

Print Technology	LED
Resolution	1200 x 1200 dpi
Processor	533 MHz
Memory	256 MB
Connectivity	USB, Ethernet
Duplex Printing	Standard
