6. Troubleshooting procedure
Upper cover
(6) Open the upper cover of the duplex unit and check for jammed paper in the duplex
unit. If jammed paper remains, pull it out. Then, close the upper cover.
(7) Return the duplex unit to the printer.
(8) Close the front cover.
(5) Pull out the duplex unit by holding the grips on its both sides.
Grip (blue)
Duplex unit
Grip (blue)
To Next Page
