ENGINE DIAG LEVEL1
SWITCH SCAN
SWITCH SCAN 00
SWITCH SCAN 01
SWITCH SCAN 02
SWITCH SCAN 03
SWITCH SCAN 04
SWITCH SCAN 05
SWITCH SCAN 06
SWITCH SCAN 07
SWITCH SCAN 08
SWITCH SCAN 09
SWITCH SCAN 10
SWITCH SCAN 11
SWITCH SCAN 12
SWITCH SCAN 13
SWITCH SCAN 14
SWITCH SCAN 15
SWITCH SCAN 16
SWITCH SCAN 17
SWITCH SCAN 18
SWITCH SCAN 19
SWITCH SCAN 20
SWITCH SCAN 21
SWITCH SCAN 22
SWITCH SCAN 23
SWITCH SCAN 24
SWITCH SCAN 25
MOTOR & CLUTCH
TEST
K-ID MOTOR
Y-ID MOTOR
M-ID MOTOR
C-ID MOTOR
BELT MOTOR
FUSER MOTOR
FUSER MTR REVERSE*
REGIST MOTOR
REGIST CLUTCH*
T1 HOPPING MOTOR
FRONT MOTOR
REGIST SHUTTER
EXIT SOLENOID
DUPLEX MOTOR
DUPLEX CLUTCH
T2 HOPPING MOTOR
T2 FEED CLUTCH
T3 HOPPING MOTOR*
T3 FEED CLUTCH*
ID UP/DOWN
LV FAN TEST
FUSER FAN TEST
TEST PRINT
PRINT EXECUTE
TEST PATTERN
CASSETTE*1
PAGE
COLOR
DUPLEX*1
MONO SPEED*2
COLOR SPEED*2
REG ADJUST TEST
REG ADJ EXECUTE
REG ADJ RESULT
BLT REFLECT TEST
BLT REFLECT RSLT
CHIP DISPERSION
ADJUST
CHIP DISPERSION
ADJUST
DENS ADJ TEST 2
DENS ADJ EXECUTE
DENS ADJ PAR-SET
DENS ADJ RESULT
AUTO CALIBRATION
NV-RAM
INITIAL
[MENU+]
[MENU-]
CONSUMABLE STATUS
FUSER UNIT
TR BELT UNIT
K-ID UNIT
Y-ID UNIT
M-ID UNIT
C-ID UNIT
K-TONER
Y-TONER
M-TONER
C-TONER
M-WASTE TNR CNT
C-WASTE TNR CNT
[MENU+]
* The item is not supported.
*1 : TRAY2 and DUPLEX are displayed only
when installed.
*2 : PU is supported from v. 00. 03. 21.
*3 : PU is supported from v. 00. 03. 21.
[MENU-]
[MENU+]
[MENU-]
[MENU+]
[MENU-]
[MENU+]
[MENU-]
[MENU+]
[MENU-]
[MENU-]
[MENU+]
[MENU-]
[MENU+]
[MENU+]
[MENU-]
[MENU+]
[MENU-]
PRINTER
STATUS
TOTAL SHEETS
FEED
K-IMPRESSIONS
Y-IMPRESSIONS
M-IMPRESSIONS
[MENU+]
[MENU-]
[MENU+]
[MENU-]
[MENU+]
[MENU-]
LOCAL
PARAMETER SET
FACTORY MODE
FUSE INTACT
ENGINE
PARAMETER SET 2
TONER SENSOR
BELT UNIT CHECK
ID UNIT CHECK
UP/DOWN
SENSOR
LED HEAD DATA*3
K LED
Y LED
M LED
C LED
[MENU+]
[MENU-]
WASTE TONER CNT
M-WASTE TNR CNT
C-WASTE TNR CNT
1
1
XXXXX
XXXXX
LEVEL1
(1) Displaying Next or Previous Menu Items
Pressing ENTER key starts the accepted test and pressing the CANCEL key ends the accepted or
started test.
: The next or previous level of a level being highlighted in green can be displayed
using MENU+ or MENU- key.
: The next or previous item of an item being non-highlighted can be displayed using
MENU+ or MENU- key after accepting with the press of ENTER key the item being
displayed.
