K 2-15 Flash Photography
Attaching Compatible Flash Units
The methods used to attach and operate external fl ash units vary with the unit. See
the documentation provided with the unit for details. The instructions here apply to
the FL-LM3.
• Confi rm that both the camera and fl ash unit are off. Attaching or removing a fl ash unit while
either the camera or fl ash unit is on could damage the equipment.
1 Remove the hot shoe cover and attach the fl ash.
• Slide the fl ash in until the foot clicks into place at the
back of the shoe.
Hot shoe cover
2 Position the fl ash head for bounce-fl ash photography
or direct lighting.
• The fl ash head can be rotated up and left or right.
• Note that fl ash output may be insuffi cient for correct
exposure when bounce fl ash lighting is used.
3 Rotate the fl ash ON/OFF lever to the ON position.
• Rotate the lever to the OFF position when the fl ash is
not in use.
ON/OFF lever
256
EN
