K 2-9 Focus
Choosing a Focus Target (AF Target Point)
The green frame showing the location of the focus point is referred to as the “AF
target”. You can position the target over your subject. At default settings, the multi
selector is used to position the AF target.
• AF-target selection is available when an option other than q (all targets) is selected for [AF
Target Mode] (P. 120).
• This setting can be accessed via:
- The multi selector - The LV super control panel (P. 124)
Access via the Multi Selector
1 Use the multi selector to position the AF target.
Multi selector
• The AF target is displayed in green at the start of the
operation.
• To select the center AF target, press the multi selector or
press and hold the OK button.
AF target
2 Take pictures.
• The AF-target selection display will clear from the
monitor.
• The AF frame is displayed in place of the selected AF
target.
• Assigning N (AF-target selection) to the arrow pad or Fn button allows the arrow pad to
be used for AF-target selection. Pressing the FGHI buttons displays the AF target. N
(AF-target selection) is assigned to the arrow pad by default.
• If you assign [N] to a control using [K Button Function] (P. 463), you can press the
control and then position the AF target using the multi selector or arrow pad. This option is
assigned to the Fn button by default.
• In [C-AF] and [C-AFb] modes, the AF target can be repositioned while focus is in progress.
%
• When [On] is selected for [AF Targeting Pad], you can reposition the AF target using monitor
touch controls while framing your subject in the viewfi nder. g [AF Targeting Pad] (P. 486)
123
EN
