4-5 Customizing Camera Functions
b Storing the Cursor Position (Menu Recall)
The camera stores the current cursor position at the time you exit the menus and
returns to that position when next the menus are displayed.
This item applies during both still photography and movie recording.
Recall
The camera stores the cursor position. The cursor appears in the saved position
the next time menus are displayed. The camera stores the position even when
off.
Reset
The camera does not store the cursor position. The W Shooting Menu 1 tab is
displayed.
b tab [Menu Recall] Choose an option
b Reducing Fisheye Distortion (Fisheye Compensation)
Reduce distortion when shooting with sheye lenses for results similar to those
produced by extremely wide-angle lenses. You can choose from three different
levels. You can also simultaneously reduce distortion when shooting under water.
This item is for still photography. See page 250 for more information.
This option is only available with compatible sheye lenses.
As of January 2019, it could be used with the M.ZUIKO DIGITAL ED 8mm f1.8 Fisheye PRO.
Angle
After correcting distortion caused by the lens, the image is cropped to
ll the frame. The picture angle of the cropped image varies with the
lens. Choose from three different crops.
j/i Correction
In addition to [Angle], the camera simultaneously corrects for distortion
occurring under water.
b tab [Fisheye Compensation] Choose an option Highlight a setting and
press the OK button
• When sheye compensation is enabled, a A icon will be displayed together with the
selected crop. To disable sheye correction, open the menu and select [Off].
[Fisheye Compensation] can be assigned to a button. It can then be turned on or off simply
by pressing the button. The control can be assigned using the [K Button Function] item in
G Custom Menu J (P. 463).
560
EN
4

Table of Contents

Other manuals for Olympus E-M1X

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Olympus E-M1X and is the answer not in the manual?

Olympus E-M1X Specifications

General IconGeneral
Megapixel20.4 MP
Camera typeMILC Body
Sensor typeMOS
Image stabilizer-
Total megapixels21.8 MP
Image sensor size4/3 \
Image formats supportedJPEG, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution5184 x 3888 pixels
Image sensor size (W x H)17.3 x 13 mm
Still image resolution(s)[RAW] 5184 x 3888 [JPEG] 5184 x 3888 - 1024 x 768
BluetoothYes
Wi-Fi standards802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version4.2
Near Field Communication (NFC)No
Digital zoom- x
Focus adjustmentAuto/Manual
Normal focusing range (tele)- m
Product colorBlack
Shooting modesAperture priority, Auto, Manual, Program, Sensitivity priority, Shutter priority
Self-timer delay2, 12 s
ISO sensitivity200, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)200
Light exposure controlProgram AE
Light exposure correction± 5EV (1/2EV; 1/3EV step)
Power source typeBattery
Battery typeBLH-1
Number of batteries supported2
Camera shutter typeElectronic, Mechanical
Fastest camera shutter speed1/32000 s
Slowest camera shutter speed60 s
Flash modesAuto, Flash off, Flash on, Manual, Red-eye reduction, Slow synchronization
Flash sync-speed1/250 s
Shoe mounting point typeHot shoe
Flash exposure correction±3EV (1/2, 1/3, 1 EV step)
Video resolutions1280 x 720, 1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Motion JPEG frame rate60 fps
Video formats supportedAVC, H.264, MPEG4
Maximum video resolution4096 x 2160 pixels
Memory slots1
Compatible memory cardsSD, SDHC, SDXC
Display diagonal3 \
Display aspect ratio3:2
Display resolution (numeric)1037000 pixels
Viewfinder typeElectronic
Viewfinder resolution2360000 pixels
USB connectorUSB Type-C
HDMI connector typeMicro
Headphone connectivity3.5 mm
Weight and Dimensions IconWeight and Dimensions
Depth75.4 mm
Width144.4 mm
Height146.8 mm
Weight849 g
Weight (including battery)997 g
