158
Chapter 10 Specifications
Measurement function
Spot ranging • Spot ranging indicates approximate value of the
distance from the distal end of the insertion tube to
the object on screen specified by the cursor.
• The distance is indicated via numerical value and
color-coded bar.
(Stereo measurement: except for profile)
Recording • It is possible to record up to 3 groups of
measurement results on the measurement screen.
• When measurement results exist, pressing and
holding the [FRZ/REC] button on the remote control
records the image together with the measurement
results.
Correction of the specified point It is possible to select and correct specified points.
(Stereo measurement only)
Restrictions • The image format is TIFF or JPEG (HIGH) with the
stereo measurement and JPEG with the scaler
measurement.
• The object distance measurement result is not
recorded.
• When a retrieved image is measured, stereo
measurement is not available unless the same
measurement environment used for to capture the
image has been register for the measurement.
• Recommended measurement range for stereo
measurement up to 15 mm
Possible measurement range up to 30 mm
• Possible to record in a maximum of eight
measurement environments.
Volume Volume adjustment of audio playback and beep
according to menu operations.
Save settings Sets whether the last or default settings are recalled
the next time the system is started up.
Connected to a PC USB cable connection. Contact Olympus for details.
