Chapter 10 Specifications
Measurement function
Measurement types Stereo measurement:
When a stereo optical adapter is used.
Scaler measurement:
When a stereo optical adapter is not used.
Spot ranging:
When a stereo optical adapter is used.
Measure
ment
modes
Distance Distance between two points indicated on the screen.
Area/Lines • Total length of lines connecting multiple points (max.
20 points) indicated on the screen.
• Area of a closed figure formed by indicating multiple
points.
(Stereo measurement only)
Point to line Distance from a point to a line (reference line) that is
defined by indicating two points on the screen.
(Stereo measurement only)
Depth Distance from a point to a plane that is defined by
indicating three points on the screen.
(Stereo measurement only)
Offset A straight line (reference line) is defined by specifying
two points on the screen, and while the distance from a
third specified point to the straight line is calculated,
the line parallel to the offset line is displayed.
(Stereo measurement only)
Multi This type of measurement automatically detects and
displays the material loss region between two specified
points, and measurements the width, depth and area.
(Stereo measurement only)
Profile This mode allows for displaying the surface profile
obtained by sectioning the target object with a plane
defined by the line connecting two specified points and
the optical center axis on the left screen.
(Stereo measurement only)
Displaying the measurement
results
• Normally, displays measurement results for the
measurement point indicated by the cursor.
• Up to 3 measurement results can be displayed.
(Stereo measurement: distance, point to line, offset,
and depth only)
