OMNI 4000/7000 Installation Guide – Rev H
3-23
Installation
Table 3-3: DT Board Back Panel Wiring for Field Devices
J1 Pinouts
Signal Name
Signal Type
1
Digital 1
Digital I/O
2
Digital 2
Digital I/O
3
Digital 3
Digital I/O
4
Digital 4
Digital I/O
5
Return
Signal Return
6
Digital 5
Digital I/O
7
Digital 6
Digital I/O
8
Digital 7
Digital I/O
9
Digital 8
Digital I/O
10
Return
Signal Return
J2 Pinouts
Signal Name
Signal Type
11
Digital 9
Digital I/O
12
Digital 10
Digital I/O
13
Digital 11
Digital I/O
14
Digital 12
Digital I/O
15
Return
Signal Return
16
Digital 13
Digital I/O
17
Digital 14
Digital I/O
18
Digital 15
Digital I/O
19
Digital 16
Digital I/O
20
Return
Signal Return
Table 3-4: Back Panel Wiring for Communication and Power
DT board Connections
Pinouts
Signal Name
Back Panel Terminal Pin
J3 and J4 for
communication
H
DT Comm Link H
DM 11 (TB1)
L
DT Comm Link L
DM 12 (TB1)
J5 and J6 for power
+
12/24 VDC
TB-11 DC+ for the OMNI 7000
TB-5 DC+ for the OMNI 4000
–
DC Return
TB-11 DC- for the OMNI 7000
TB-5 DC- for the OMNI 4000
