Omni 7000 Series Installation Guide

OMNI 4000/7000 Installation Guide – Rev H
4-36
Configuration
8.
When you have finished adding units,
click OK to exit the remaining open
windows, Setup Unit and then Setup
Communications.
9.
You can repeat the previous steps to add
more serial port sites and units.
Connecting through an Ethernet Port
To connect through an Ethernet port, follow these instructions:
1.
Click the Home tab on the
OMNICONNECT ribbon.
2.
Click the Sites button in the Home ribbon
to open the Setup Sites window.
3.
In the Setup Sites window, click Add
Site to open the Setup Communications
window.
4.
a. In the Setup Communications
window, select TCP/IP from the
Media Type drop-down list.
b. In the Site Name field, enter a
name for this site
5.
Click Add Unit to open the Setup Unit
window.
