CHAPTER 12
| 88
FM MENU EXPERT MODE
Sidechain PEQ
A fully-adjustable, 3-band Sidechain Parametric Equalizer is available, which allows you to make it more or less sensitive
to particular frequencies. When the controls are not set to cut or boost any frequency, the Input AGC reacts to the full audio
spectrum. When set to cut or boost a particular range of frequencies, the Input AGC becomes less sensitive (cut) or more
sensitive (boost).
Wideband AGC 3
Main
The Wideband AGC3 menu operates in the same manner as Wideband AGC2, with all of the same controls, but with one
difference: It cannot be used as a wideband compressor before the multiband section, only after. It can, however, be used in the
Bass Only or Bass Wideband mode just like Wideband AGC2.
