CHAPTER 23
| 186
SYSTEM MENU
Task Scripts
The new task scripting function allows you to assign just about any Omnia.9 function to GPIO Functions or for dayparting.
This feature is not directly accessible from NfRemote or the front panel, access is through the HTTP server only. However,
when you’ve created your task scripts, you will see them in the GPI and Scheduling sections in both NfRemote and on the front
panel.
Make sure you’ve added your workstation’s IP to the HTTP access whitelist (Home / System / System Configuration / HTTP
Access). Then connect to the Omnia.9’s HTTP interface.
http://your-omnia9-ip:7380/
You should see this page:
Welcome to Omnia.9 mkII HTTP server - version 3.18.99 x64 [Refresh]
Host: OMNIA9-99901
♦ List Parameters
♦ Preset Manager
♦ Launch Remote Interface (Windows Application)
♦ Log Files
♦ Task Scripts
♦ Internal Playback Log - Input 1
♦ Internal Playback Log - Input 2
Downloadables
Download Remote Interface (Windows Application): http://your-omnia9-ip:7380/NfRemote.exe
Right-click on “List Parameters” and open the link in a new browser tab or window.
Leave the parameter list alone for now.
Click on “Task Scripts”.
Click on Create to create new task.
You’ll see several example lines. They’re there to show you what it’s supposed to look like, but you should delete them.
Now we need to find out the path to the parameter you actually DO want to change.
Just go to the parameter you want to change in NfRemote, right click on it, and select “Copy Path”.
