CHAPTER 22
| 153
MONITOR OUTPUT MENU
Delay Phase Menu
♦ The Volume and Master Gain controls are duplicates of those found in the Main menu, but are found here as well for
convenience.
♦ The Delay All control allows you to delay the audio output of the Speaker and Headphone outputs.
♦ The Delay Left and Delay Right controls provide a means by which to delay one channel independently of the other.
♦ The Invert Left and Invert Right controls let you swap the polarity of each channel. The ability to do so in one channel
or the other can be useful if you discover that one of the speakers has been wired out of phase and it is not practical or
convenient to physically switch the positive and negative wires. Being able to do so to both channels simultaneously can
come in handy if you are in a situation where both channels have gotten out of phase at some point in the studio wiring.
Channel Coupling Menu
♦ When enabled, the Common L/R EQ control “couples” the left and right channels together in the parametric equalizer
so that any changes make to the left channel will also be made in the right, eliminating the need to make the same
adjustments twice. Disabling this control allows you to EQ the left and right channels differently. This can be useful if, for
instance, one speaker is placed in the corner of a room while the other is not, resulting in a different bass response at the
monitoring point.
♦ The Common L/R Delay ensures that any delay to the left and right speaker outputs is identical in time. If an operator
wants to have a different delay time for left versus right speaker output, then disable this option, i.e. turn the yellow
button off. Then go to the previous submenu, Delay Phase, where you can now apply different delay times separately to
left and right.
