CHAPTER 12
| 89
FM MENU EXPERT MODE
Sidechain PEQ
Similar to the Wideband AGC 1 and 2, another fully-adjustable, 3-band Sidechain Parametric Equalizer is available here,
which allows you to make it more or less sensitive to particular frequencies. When the controls are not set to cut or boost any
frequency, the Input AGC reacts to the full audio spectrum. When set to cut or boost a particular range of frequencies, the Input
AGC becomes less sensitive (cut) or more sensitive (boost).
Band Mix
The Band Mix Menu allows you to adjust the final output of each band after all Wideband and Multiband processing has been
applied. It can be used very effectively to tailor the overall spectral balance of your sound, but keep in mind that this is the
final point of adjustment before the audio reaches the Final Clipper (FM and AM cores) or Final Limiter (HD and Streaming
Cores). In other words, levels increased in the Band Mix section can only be controlled by final clipping or final limiting, which
may result in unexpected or unwanted density on some material, so care is required when making adjustments here.
♦ Each Band Level control has a range of -12 to +12dB in one-quarter dB increments.
♦ The Band Mix (coupled) control allows you to adjust the output of all bands in the Band Mix section simultaneously and
by an equal amount.
