3 Nomenclature and Functions
3-22
CJ2 CPU Unit Hardware User’s Manual
The following table shows the maximum total power that can be supplied at 5 VDC and 24 VDC.
For details on the current consumption of individual Units, refer to 2-1-2 CPU Rack, 2-1-3 Expansion
Racks, and 2-1-4 Configuration Units. Refer to 2-1-5 Calculating Unit Current Consumption for an
example of calculating the current consumption.
Condition 2: Power Requirements
Model Maximum total power output
CJ1W-PA205R/205C 25 W
CJ1W-PA202 14 W
CJ1W-PD025 25 W
CJ1W-PD022 19.6 W
