CJ2 CPU Unit Hardware User’s Manual
A-3 Fatal and Non-fatal Error Details
App
A-3-1 Fatal Errors
A-3 Fatal and Non-fatal Error Details
This appendix describes the fatal and non-fatal errors that can occur in the CPU Unit.
Operation will stop if a fatal error occurs. Information on the fatal error is displayed on the Error Tab
Page opened from the CX-Programmer's PLC Error Window. Check the details on the error based on
the message that is displayed, and the error flags and error information in the Auxiliary Area, and take
suitable countermeasures. The following list shows the fatal errors.
A-3-1 Fatal Errors
Fatal error
Cycle Time Error (0x809F)
IO Bus Error (0x80C0 to 0x80C7, 0x80CE , or 80CF)
IO Setting Error (0x80E0)
Too Many I/O Points Error (0x80E1)
Unit Number Duplication Error (0x80E9)
Rack Number Duplication Error (0x80EA)
Programe Error (0x80F0)
Instruction error
Indirect BCD error
Illegal access error
No END error
Task error
Differentiation overflow error
Illegal instruction error
UM overflow error
Memory Error (0x80F1)
Card Transfer Error (0x80F4)
System Failure (FALS) Error (0xC101 to 0xC2FF)
Version Error (0x80F2)

Omron CJ2 Specifications

General

Model	CJ2
Manufacturer	Omron
Type	Programmable Logic Controller (PLC)
CPU Units	Multiple models available (e.g., CJ2M, CJ2H)
Number of I/O Points	Up to 2, 560 points
Communication Ports	Ethernet/IP, EtherCAT, USB, Serial
Expansion	Yes, via I/O Units and Special I/O Units
I/O Control Method	Cyclic Scan, Interrupt
Programming Language	Ladder diagram, structured text, function block diagram, sequential function chart, instruction list
Built-in I/O	Available on some models (e.g., CJ2M)
Ethernet Port	Yes, 1 port (depending on CPU Unit)
Serial Ports	RS-232C, RS-422/485 (configurable)
USB Port	Yes (for programming and monitoring)
Operating Temperature	0°C to 55°C
Storage Temperature	-25 to 70°C
Humidity	10 to 95% RH (non-condensing)
Vibration Resistance	10 to 57 Hz, Amplitude: 0.075 mm, 57 to 150 Hz, Acceleration: 1 G, X, Y, and Z directions, 80 min each
Power Supply Voltage	24 VDC or 100 to 240 VAC (depending on CPU Unit)
