Omron CJ2 - Dimensions; A-2-1 CJ2 H CPU Units; A-2-2 Power Supply Units

Appendices
A-86
CJ2 CPU Unit Hardware User’s Manual
A-2 Dimensions
A-2-1 CJ2H CPU Units
A-2-2 Power Supply Units
CJ1W-PA205R
65
79.8 74.5
2.7
2.7
90
66.2
POWER
PA205R
DC24V
AC240V
OUTPUT
RUN
INPUT
AC100-240V
L2/N
L1
65
80
81.6
90
