CJ2 CPU Unit Hardware User’s Manual
4-1 Support Software
4
4-1-1 CX-One FA Integrated Tool Package
Application CX-One Software Description
Programming
CX-Programmer Basic software for creating and debugging PLC programs.
SwitchBox Utility Utility software to support PLC debugging operations.
Network settings
CX-Integrator
Software for starting and setting FA networks, such as Controller Link,
DeviceNet, CompoWay/F, Ethernet, and CompoNet. Includes routing
table components, data link components, and DeviceNet Configurator
functions.
Network Configurator Software for setting tag data links for the built-in EtherNet/IP port.
CX-FLnet
Software for making FL-net Unit system settings and performing moni-
toring.
Touch-panel screen
creation
CX-Designer
Software for creating screen data for touch panel NS-series PTs.
Protocol macro cre-
ation
CX-Protocol
Software for creating protocols (protocol macros) for exchanging data
with general-purpose external devices connected to Serial Communica-
tions Boards/Units and Option Boards.
Simulation CX-Simulator
Software for simulating PLC operations on a personal computer and
debugging programs without requiring a CPU Unit.
Motion Control
CX-Position Software for creating and monitoring data for Position Control Units.
CX-Motion-NCF
Software for creating and monitoring data for Position Control Units
(MECHATROLINK communications models).
CX-Motion-MCH
Software for creating data for Motion Control Units (MECHATROLINK
communications models), and for creating and monitoring motion pro-
grams.
CX-Motion
Software for creating data for Motion Control Units, and for creating and
monitoring motion programs.
Servo/Inverter set-
tings
CX-Drive
Software for setting and adjusting Inverter and servo data.
PLC-based process
control
CX-Process Tool
Software for creating and debugging function blocks for Loop Controllers
(Loop Control Units/Boards, Process CPU Units, and Loop CPU Units).
Face Plate Auto-
Builder for NS
Software for automatic generation of screen data (project files) for touch
panel NS-series PTs from Loop Controller function block tag informa-
tion.
Temperature control
settings
CX-Thermo
Software for setting and adjusting Temperature Controller parameters.

Omron CJ2 Specifications

General

Model	CJ2
Manufacturer	Omron
Type	Programmable Logic Controller (PLC)
CPU Units	Multiple models available (e.g., CJ2M, CJ2H)
Number of I/O Points	Up to 2, 560 points
Communication Ports	Ethernet/IP, EtherCAT, USB, Serial
Expansion	Yes, via I/O Units and Special I/O Units
I/O Control Method	Cyclic Scan, Interrupt
Programming Language	Ladder diagram, structured text, function block diagram, sequential function chart, instruction list
Built-in I/O	Available on some models (e.g., CJ2M)
Ethernet Port	Yes, 1 port (depending on CPU Unit)
Serial Ports	RS-232C, RS-422/485 (configurable)
USB Port	Yes (for programming and monitoring)
Operating Temperature	0°C to 55°C
Storage Temperature	-25 to 70°C
Humidity	10 to 95% RH (non-condensing)
Vibration Resistance	10 to 57 Hz, Amplitude: 0.075 mm, 57 to 150 Hz, Acceleration: 1 G, X, Y, and Z directions, 80 min each
Power Supply Voltage	24 VDC or 100 to 240 VAC (depending on CPU Unit)
