Omron CJ2 User Manual

8-15
8 Backup Operations
CJ2 CPU Unit Hardware User’s Manual
8-3 Simple Backup
8
8-3-6 Data Backed Up Using Simple Backup
In order for data in a Unit to be backed up, that Unit must support the simple backup function. Refer to
the operation manual for the specific Unit to check whether this function is supported.
Precautions for Correct UsePrecautions for Correct Use
When using a simple backup file to restore data, use a CPU Unit of the same model as the
backup source. If a CPU Unit of a different model is used, the following operations will result.
• If the number of EM banks for the simple backup file is greater than that of the CPU Unit where
the data is to be restored, the data will not be restored.
• If the number of EM banks for the simple backup file is less than that of the CPU Unit where
the data is to be restored, the data in the EM bank areas in the simple backup file will be
restored, but forced status will not be restored. In addition, EM banks that are not in the simple
backup file will retain their values from before the restoration.
Applicable Units Model numbers Data backed up for simple backup
Data capacity used
in Memory Card
Serial Communica-
tions Units
CJ1W-SCU21
CJ1W-SCU41
CJ1W-SCU21-V1
CJ1W-SCU31-V1
CJ1W-SCU41-V1
Protocol macro data (Including both stan-
dard system protocols and user-defined
protocols from the flash memory in the
Unit or Board)
129 Kbytes
FL-net Units CJ1W-FLN22 Data link tables 1.3 Kbytes
DeviceNet Units CJ1W-DRM21 Device parameters (all data in EEPROM in
the Unit)
(Although this is the same data as is
backed up from the Memory Card backup
function supported by the Unit or the
DeviceNet Configuration (Ver. 2.@), there
is no file compatibility.)
7 Kbytes
CompoNet Units CJ1W-CRM21 • Registration tables
• Software settings
• Network parameters
• Slave parameters
3.5 Kbytes
Motion Control Units CJ1W-MCH71 • Positioning data
• System parameters
• G-language programming
8,192 Kbytes
Position Control
Units
CJ1W-NCF71 • Common parameters
• Individual axis parameters
64 Kbytes
CJ1W-
NC113/133/213/233/
413/433
• Axis parameters
• Sequence data
• Speed data
• Acceleration/deceleration time data
• Dual timer data
• Zone data
7 Kbytes
EtherNet/IP Unit CJ1W-EIP21 • Unit settings
• Tag data link settings
459 Kbytes

Omron CJ2 Specifications

General

Model	CJ2
Manufacturer	Omron
Type	Programmable Logic Controller (PLC)
CPU Units	Multiple models available (e.g., CJ2M, CJ2H)
Number of I/O Points	Up to 2, 560 points
Communication Ports	Ethernet/IP, EtherCAT, USB, Serial
Expansion	Yes, via I/O Units and Special I/O Units
I/O Control Method	Cyclic Scan, Interrupt
Programming Language	Ladder diagram, structured text, function block diagram, sequential function chart, instruction list
Built-in I/O	Available on some models (e.g., CJ2M)
Ethernet Port	Yes, 1 port (depending on CPU Unit)
Serial Ports	RS-232C, RS-422/485 (configurable)
USB Port	Yes (for programming and monitoring)
Operating Temperature	0°C to 55°C
Storage Temperature	-25 to 70°C
Humidity	10 to 95% RH (non-condensing)
Vibration Resistance	10 to 57 Hz, Amplitude: 0.075 mm, 57 to 150 Hz, Acceleration: 1 G, X, Y, and Z directions, 80 min each
Power Supply Voltage	24 VDC or 100 to 240 VAC (depending on CPU Unit)
