2-17
2 Basic System Configuration and Devices
CJ2 CPU Unit Hardware User’s Manual
2-1 Basic System Configuration
2
2-1-4 Configuration Units
z CJ-series CPU Bus Units
*1 Slave I/O are allocated in DeviceNet Area (CIO 3200 to CIO 3799).
*2 Some CJ-series CPU Bus Units are allocated words in the CPU Bus Unit Setting Area. The system must be designed so
that the number of words allocated in the CPU Bus Unit Setting Area does not exceed its capacity. Refer to 4-6-2 Proce-
dure for Setting CPU Bus Unit Setup Area in the CJ2 CPU Unit Software User’s Manual (Cat. No. W473).
*3 Increases by 0.15 A/Unit when an NT-AL001 RS-232C/RS-422A Link Adapter is used. Increases by 0.04 A/Unit when a
CJ1W-CIF11 RS-422A Conversion Unit is used.
*4 When mounting to a CJ-series CPU Rack or a CJ-series Expansion Rack, one of these Units uses the space of three
Units.
*5 Includes the weight of accessory connectors.
*6 Use version 2 or higher of the SYSMAC SPU Unit with a CJ2 CPU Unit.
Type Name Specifications Model
Number of
words allo-
cated (CIO
1500 to CIO
1899)
Unit No.
Current consumption
(A)
Weight
5 VDC 24 VDC
CPU Bus
Units
*2
High-speed
Analog Input
Unit
4 inputs: 80 µs/2 inputs,
160 µs/4 inputs
CJ1W-ADG41 25 words 0 to F 0.65 --- 150 g max.
Controller Link
Units
Wired data links CJ1W-CLK23 25 words 0 to F 0.35 --- 110 g max.
Serial Commu-
nications Units
One RS-232C port and
one RS-422A/485 port
CJ1W-SCU41-V1 25 words 0 to F
0.38
*3
--- 110 g max.
Two RS-232C ports CJ1W-SCU21-V1
0.28
*3
Two RS-422A/485 ports CJ1W-SCU31-V1 0.38
Ethernet Units 100Base-TX, FINS
communications, socket
service, FTP server,
and mail communica-
tions
CJ1W-ETN21 25 words 0 to F
(4 Units
max.)
0.38 --- 110 g max.
CPU Bus
Units
*2
EtherNet/IP
Unit
Tag data links, FINS
communications, CIP
message communica-
tions, FTP server, etc.
CJ1W-EIP21 25 words 0 to F 0.41 --- 94 g max.
FL-net Unit 100Base-TX cyclic
transmissions and mes-
sage transmissions
CJ1W-FLN22 25 words 0 to F
(4 Units
max.)
0.37 --- 100 g max.
DeviceNet Unit DeviceNet remote I/O,
2,048 points; Both Mas-
ter and Slave functions,
Automatic allocation
possible without Config-
urator
CJ1W-DRM21
25 words
*1
0 to F 0.29 ---
118 g max.
*5
Position Con-
trol Units sup-
porting
MECHA-
TROLINK-II
communica-
tions
MECHATROLINK-II,
16 axes max.
CJ1W-NCF71 25 words 0 to F 0.36 --- 95 g max.
Motion Control
Units support-
ing MECHA-
TROLINK-II
communica-
tions
*4
MECHATROLINK-II,
Real axes: 30 max.,
Virtual axes: 2 max.,
Special motion control
language
CJ1W-MCH71 25 words 0 to F 0.60 0.80 210 g max.
SYSMAC SPU
Unit (High-
speed Storage
and Process-
ing Unit)
One CF card type I/II
slot (used with OMRON
HMC-EF@@@ Memory
Card), one Ethernet
port
CJ1W-SPU01-
V2
*6
Not used. 0 to F 0.56 --- 180 g max.

Omron CJ2 Specifications

General

Model	CJ2
Manufacturer	Omron
Type	Programmable Logic Controller (PLC)
CPU Units	Multiple models available (e.g., CJ2M, CJ2H)
Number of I/O Points	Up to 2, 560 points
Communication Ports	Ethernet/IP, EtherCAT, USB, Serial
Expansion	Yes, via I/O Units and Special I/O Units
I/O Control Method	Cyclic Scan, Interrupt
Programming Language	Ladder diagram, structured text, function block diagram, sequential function chart, instruction list
Built-in I/O	Available on some models (e.g., CJ2M)
Ethernet Port	Yes, 1 port (depending on CPU Unit)
Serial Ports	RS-232C, RS-422/485 (configurable)
USB Port	Yes (for programming and monitoring)
Operating Temperature	0°C to 55°C
Storage Temperature	-25 to 70°C
Humidity	10 to 95% RH (non-condensing)
Vibration Resistance	10 to 57 Hz, Amplitude: 0.075 mm, 57 to 150 Hz, Acceleration: 1 G, X, Y, and Z directions, 80 min each
Power Supply Voltage	24 VDC or 100 to 240 VAC (depending on CPU Unit)
