Omron CPM1 Programming Manual

402
CQM1 Cycle Time and I/O Response Time Section 7-1
37 XNRW 41.9
Constant V
word → word
2.5
45.1
Word V word → word
114.1
*DM V
*DM → *DM
38 INC 27.8 When incrementing a word 1.5
50.1 When incrementing *DM
39 DEC 28.4 When decrementing a word 1.5
50.8 When decrementing *DM
40 STC 12.0 Any 1.0
41 CLC 12.0 1.0
45 TRSM 28.8 1.0
46 MSG 24.6 With message in words 1.5
48.4 With message in *DM
50 ADB 53.4 Constant + word → word 2.5
56.6 Word + word → word
125.6 *DM + *DM → *DM
51 SBB 53.4 Constant – word → word 2.5
56.6 Word – word → word
125.6 *DM – *DM → *DM
52 MLB 45.7 Constant × word → word 2.5
48.9 Word × word → word
116.4 *DM × *DM → *DM
53 DVB 46.7 Word ÷ constant → word 2.5
49.9 Word ÷ word → word
117.4 *DM ÷ *DM → *DM
54 ADDL 59.3 Word + word → word 2.5
128.9 *DM + *DM → *DM
55 SUBL 59.3 Word – word → word 2.5
128.9 *DM – *DM → *DM
56 MULL 204.5 Word × word → word 2.5
271.2 *DM × *DM → *DM
57 DIVL 205.9 Word ÷ word → word 2.5
272.6 *DM ÷ *DM → *DM
58 BINL 76.0 Word → word 2.0
120.6 *DM → *DM
59 BCDL 60.9 Word → word 2.0
105.6 *DM → *DM
70 XFER 72.9 When transferring a constant to a word 2.5
76.1 When transferring a word to a word
2.90 ms When transferring 1,024 words using *DM
16.66 ms When transferring 6,144 words using *DM
71 BSET 45.6 When setting a constant to 1 word 2.5
77.9 When setting word constant to 10 words
1.93 ms When setting *DM to 1,024 words
10.95 ms When setting *DM to 6,144 words
72 ROOT 63.9 Word calculation → word 2.0
110.8 *DM calculation → *DM
73 XCHG 40.9 Word → word 2.0
85.5 *DM → *DM
Code Mnemonic ON execution
time (µs)
Conditions (Top: min.; bottom: max.) OFF execution time (µs)

Omron CPM1 Specifications

General

Model	CPM1
Manufacturer	Omron
Instruction Set	Basic and advanced instructions
Power Supply	100 to 240 VAC or 24 VDC
Communication	RS-232C
I/O Points	10, 20, 30, or 40 points depending on the model
Timers	Yes, multiple timers available
Counters	Yes, multiple counters available
Input Voltage	24V DC
Output Type	Relay or transistor
Number of I/O Points	10, 20, 30, 40
Communication Ports	RS-232C (optional)
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C
Humidity	10% to 90% (non-condensing)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
Program Memory	2048 steps (2K steps)
