SRM1 Cycle Time and I/O Response Time Section 7-3
7-3-5 Interrupt Processing Time
This section explains the processing times involved from the time an interrupt
is executed until the interrupt processing routine is called, and from the time
an interrupt processing routine is completed until returning to the initial loca-
tion. This explanation applies to input, interval timer interrupts.
1,2,3... 1. Source of interrupt
2. Wait for completion of interrupt-mask processing
3. Change to interrupt processing
4. Interrupt routing (CPM1A only)
5. Return to initial location
The table below shows the times involved from the generation of an interrupt
signal until the interrupt processing routine is called, and from when the inter-
rupt processing routine is completed until returning to the original position.
Mask Processing
Interrupts are masked during processing of the operations described below.
Until the processing is completed, any interrupts will remain masked for the
indicated times.
Generation and clearing of non-fatal errors:
When a non-fatal error is generated and the error contents are registered
at the SRM1, or when an error is being cleared, interrupts will be masked
for a maximum of 100
µs until the processing has been completed.
Online editing:
Interrupts will be masked for a maximum of 600 ms (i.e.: editing DM 6144
to DM 6655) when online editing is executed during operation. In addition,
the system processing may have to wait for a maximum of 170
µs during
this processing.
Item Contents Time
Wait for completion of
interrupt-mask processing
This is the time during which interrupts are waiting until processing has been
completed. This situation occurs when a mask processes is executed. It is
explained below in more detail.
See below.
Change to interrupt
processing
This is the time it takes to change processing to an interrupt. 15 µs
Return This is the time it takes, from execution of RET(93), to return to the process-
ing that was interrupted.
15 µs

Omron CPM1 Specifications

General

Model	CPM1
Manufacturer	Omron
Instruction Set	Basic and advanced instructions
Power Supply	100 to 240 VAC or 24 VDC
Communication	RS-232C
I/O Points	10, 20, 30, or 40 points depending on the model
Timers	Yes, multiple timers available
Counters	Yes, multiple counters available
Input Voltage	24V DC
Output Type	Relay or transistor
Number of I/O Points	10, 20, 30, 40
Communication Ports	RS-232C (optional)
Operating Temperature	0°C to 55°C
Storage Temperature	-20°C
Humidity	10% to 90% (non-condensing)
Dimensions	Varies depending on the model
Weight	Varies depending on the model
Program Memory	2048 steps (2K steps)
