8-4 Mode Setting
8
8-4-2 Monitor Mode
• This indicates the regeneration resistance load ratio as a percentage when the detection level for the
regeneration overload is 100%.
• This indicates the overload ratio as a percentage when the rated load is 100%.
Warning Number
Regeneration Load Ratio
Overload Load Ratio
Inertia Ratio
Press to display the occurrence status of each warning.
... Warning occurs
... No warning
,
Warning number
The inertia ratio (%) is displayed.
