10 - 9
10 Troubleshooting and Maintenance
OMNUC G5-series (Pulse-train Input Type) AC Servomotors and Servo Drives User’s Manual
10-3 Alarm List
10
*1 “Immediate stop” means alarms which cause an immediate stop when Stop Selection for Alarm Detection
(Pn510) is set to 4 to 7. For details, refer to Stop Selection for Alarm Detection on page 7-46.
87 0 Emergency Stop Input
Error
An emergency stop input signal (STOP)
was input.
95 0-4 Motor Non-conformity The combination of the Servomotor and
Servo Drive is not appropriate.
The encoder was not connected when the
power supply was turned ON.
––
Other
numbers
Other errors The control circuit malfunctioned due to
excess noise or some other problem.
––
Alarm No.
Error detection function Description and error cause
Attribute
Main
Sub
History
Can be
cleared
Immediate
stop
*1
