2 - 29
2 Models and External Dimensions
OMNUC G5-series (Pulse-train Input Type) AC Servomotors and Servo Drives User’s Manual
2-4 External and Mounting Dimensions
2
2-4-1 Servo Drive Dimensions
 Wall Mounting
3-phase 200 VAC: R88D-KP30H/-KP50H (3 to 5 kW)
R2.6
R2.6
φ5.2
R2.6 R2.6
φ5.2
212
3
130
100
15
65
5.2
5.2
220 240 250
5.2
5.2
65
15
100
70
External Dimensions
6-M4
50
240
100
130
15
220
Mounting dimensions
