2 Models and External Dimensions
2 - 30
OMNUC G5-series (Pulse-train Input Type) AC Servomotors and Servo Drives User’s Manual
 Front Mounting (Using Front Mounting Brackets)
R2.6
R2.6
φ5.2
R2.6R2.6
φ5.2
130
100
15
65
5.2
5.2
220 240 250
5.2
5.2
65
100
15
212
40.7
2.5
2.5
70
External Dimensions
Rectangular hole
6-M4
50
240
100
(132)*
16
(228)*
6
* Rectangular hole dimensions are reference values.
Mounting dimensions
