2 Models and External Dimensions
2 - 52
OMNUC G5-series (Pulse-train Input Type) AC Servomotors and Servo Drives User’s Manual
For 1,000-r/min Servomotors (900 W to 3 kW)
Note 1 The standard shaft type is a straight shaft.
2 A model with a key and tap is indicated with J at the end of the model number (the suffix shown in the box). (Example:
R88G-HPG32A05900TBJ)
3 The diameter of the motor shaft insertion hole is the same as the shaft diameter of the corresponding Servomotor.
4 For Servomotors with a key, remove the key before use.
Outline drawing 1
Model
Outline
drawing
Dimensions [mm]
LM
LR C1 C2 D1 D2 D3 D4 D5 E F1
F2
900 W
1/5
R88G-HPG32A05900TB 1
129 133 120
130 135 145 115 114 84 98
12.5
35
1/11
R88G-HPG32A11900TB 1
129 133 120
130 135 145 115 114 84 98
12.5
35
1/21
R88G-HPG50A21900TB 1
149 156 170
130 190 145 165 163 122 103
12
53
1/33
R88G-HPG50A33900TB 1
149 156 170
130 190 145 165 163 122 103
12
53
2 kW
1/5
R88G-HPG32A052K0TB 1
129 133 120
180 135 200 115 114 84 98
12.5
35
1/11
R88G-HPG50A112K0TB 1
149 156 170
180 190 200 165 163 122 103
12
53
1/21
R88G-HPG50A212K0TB 1
231 222 230
180 260 200 220 214 168 165
12
53
1/25
R88G-HPG65A255K0SB 1
231 222 230
180 260 200 220 214 168 165
12
57
3 kW
1/5
R88G-HPG50A055K0SB 1
149 156 170
180 190 200 165 163 122 103
12
53
1/11
R88G-HPG50A115K0SB 1
149 156 170
180 190 200 165 163 122 103
12
53
1/20
R88G-HPG65A205K0SB 1
231 222 230
180 260 200 220 214 168 165
12
57
1/25
R88G-HPG65A255K0SB 1
231 222 230
180 260 200 220 214 168 165
12
57
C1
4-φZ1
φSh7
φD5
φD4
φD3h7
*1
E
T
F1
F2
LR
G
LM
C2
φD2
φD1
4-Z2
Set bolt (AT)
Key tap dimensions
QK
b
h
t1
M depth L
*1 The tolerance is “h8” for R88G-HPG50 or R88G-HPG65.
