Omron M1 Series User Manual

Parame-
ter No.
Da-
ta
Description Reference item Page
E20, E21,
E27
105 DBAL: Braking transistor broken
Braking transistor broken
(DBAL)
page
7-98
111 Do not set. - -
112 Do not set. - -
113 Do not set. - -
114 Do not set. - -
115 Do not set. - -
116 Do not set. - -
117 Do not set. - -
118 Do not set. - -
119 Do not set. - -
120 Do not set. - -
132 TRQ: Torque limit Torque limit function
page
6-81
151 OT-OUT: Overtravel detection Over-travel
page
6-43
152 STOP-OUT: Forced stop detection Forced Stop
page
7-152
182 BER: Brake error Brake control function
page
6-72
183 FDT3: Set-frequency-only arrival signal
Frequency arrival signal
page
7-89
185 FDT4:
Set-frequency-only arrival signal
2
186 FBV: PID FB status output PID function
page
7-123
187 FR: Starting contact signal Starting contact signal
page
7-101
188 FREF: Frequency Command Source
Frequency reference selection
status signal
page
7-105
206 LOG1: Logic operation output 1
Logical operation function
page
7-94
207 LOG2: Logic operation output 2
208 LOG3: Logic operation output 3
209 NDc: Network error
Communications disconnec-
tion detection signal
page
7-101
236 ONT: Power ON time over
RUN time/Power ON time
over
page
7-92
237 RNT: RUN time over
238 AI1Dc:
Analog AI1 disconnection detec-
tion
Window comparator
page
7-103
239 AIVDc:
Analog AI2 (AIV) disconnection
detection
240 WAC: Capacitor life warning signal Capacitor life warning signal
page
7-96
241 WAF: Cooling fan life warning signal Cooling fan life warning signal
page
7-99
7 Other Functions
7-34
M1 Series Standard Type User's Manual (I669)
