Parame-
ter No.
Da-
ta
Description Reference item Page
E20, E21,
E27
48 SWM1: 1st motor in operation
1st control under selection
signal
page
7-105
49 SETM: 2nd motor in operation
2nd control under selection
signal
52 FWR: Forward run signal Forward run signal
page
5-69
53 RVR: Reverse run signal Reverse run signal
page
5-69
54 RMT: Under remote mode Forced operator
page
7-75
56 MOH:
Motor overheat detected by ther-
mistor
Thermistor Trip Function
page
7-88
57 BRK: Brake release Brake control function
page
6-72
59 AIIDc:
Analog AI2 (All) disconnection
detection
Window comparator
page
7-103
70 ZS: 0 Hz signal 0 Hz detection function
page
5-71
71 DSAG: Speed agreement
Motor control method with
speed sensor
page
6-12
72 FAR3: Frequency arrival signal 3 Frequency arrival signal
page
7-89
76 DSE: Excessive speed deviation
Motor control method with
speed sensor
page
6-12
77 U-EDC:
Low DC link bus voltage detec-
tion
Low DC link bus voltage de-
tection
page
7-106
79 IPF2:
During decelerating at momenta-
ry power failure
Restart after Momentary Pow-
er Failure
page
7-56
82 POK: Position ready Position control
page
6-36
84 MNT: Maintenance timer counted up Maintenance monitor
page
7-93
87 FAR1FDT1: Frequency match detection Frequency arrival signal
page
7-89
89 PTD: Pole tuning done Synchronous motor (PM)
page
6-20
90 Do not set. - -
91 Do not set. - -
92 Do not set. - -
93 Do not set. - -
95 Do not set. - -
98 L-ALM: Minor alarm Minor alarm list
page
7-108
99 AL: Alarm output Alarm list
page
5-71
101 DECF: EN circuit failure detected
Safety function (Set by the
EDM selector switch)
page
7-70
102 EDM:
STO (Safe Torque Off) Perform-
ance Monitor
7 Other Functions
7-33
M1 Series Standard Type User's Manual (I669)
7-2 Multifunction Input/Output Functions List
7
7-2-2 Multifunction Output Selection
