Debug Console Window Section 3-9
87
Registered Condition
Describe the Conditional Equation to register in the I/O
Condition equation. Insert the contents set in the Insert
Equation, insert by Logical Operator button, and paste
from the clip board are possible.
DEL button Delete the contents of the Con-
ditional Equation.
or button Insert the character string "or" as
a logical operator.
and button Insert the character string "and"
as a logical operator.
Condition
<< button Insert the contents set in the
Insert Equation to the Condi-
tional Equation.
Delay time Input the delay time (unit: ms) to be registered to the
I/O condition Equation.
Describe the Output Equation to be registered in the
I/O Condition equation.
Insert the contents set in the Insert Equation, insert by
[Operator] button, and paste from the clipboard are
possible.
DEL button Delete the contents of Output
Equation.
and button Insert the character string "and"
as a logical operator.
Output
<< button Insert the contents set in the
Insert Equation.
Insert Equation
Insert Equation
Select
Select which to insert the Bit Conditional Equation or
the Word Conditional Equation
Set the Bit Conditional Equation to be inserted to the
Conditional/Output Equation.
Value Select Select which is the value of
Conditional Equation, fixed (up-
per) or I/O memory (lower).
Type Select I/O memory type.
Address Input the address of I/O memory
type.
Operation Select from either = or NOT.
Selecting NOT will not reflect the
value to the Conditional Equa-
tion/Output Equation.
Bit Conditional
Equation
Value For "Fixed Value", select
ON/OFF as Bit information in the
drop down list. For "I/O Memory",
set the type and the address.
