Starting and Exiting from CX-Simulator Menus Section 3-3
42
3-3 Starting and Exiting from CX-Simulator Menus
This section describes how to start and exit the CX-Simulator.
Note
Use this method to start the CX-Simulator in the following cases:
• When the CX-Simulator performs serial communications using a computer’s
serial port.
• When performing communications via a FinsGateway network.
• When specifying a PLC data directory and saving or reading UM or I/O
memory data for the Ladder Engine.
3-3-1 Starting CX-Simulator
The following shows the CX-Simulator’s startup procedure.
1,2,3…
3. After clicking the [Start] button on the task bar, select [program] | [Omron] |
[CX-One] | [CX-Simulator] as shown below. (If installed in the CX-Simulator
group.)
[Select PLC] of the CX-Simulator setup wizard will be displayed as shown
below.
