Running by Virtual External Inputs Section 8-4
180
Pausing the Data Replay Tool
Clicking the [Pause] button in the [Run] window will pause the data replay.
Also, the following conditions of the Ladder Engine will pause the replay.
Conditions of the
Ladder Engine
Synchronous/Asynchronous How to clear
Program/Run mode Synchronous/Asynchronous Scan Run for Synchronous
and Continuous Run (Monitor
mode) for Asynchronous.
Break on Break Points Synchronous Scan Run
Break on I/O Break
Condition
Synchronous Scan Run
Note
Keep the Ladder Engine in Scan Run Status while synchronizing the Data
Replay Tool. If Continuous Run (Monitor Mode) or Continuous Scan Run is
used, synchronism in the unit of a scan will be lost. When the program has
been interrupted on a break point, etc., resume it with Scan Run.
Note
While executing asynchronously, the data will be replayed even while the
Ladder Engine is not executing a ladder program.
Getting monitor data using
the Data Replay Tool
The Data Replay Tool can save only the monitor data of the specified I/O
memory areas to the output file regardless of the Replay File. When outputting
only the monitor data, specify only an output file (and the template file as
required), not the Replay File.
8-4-3 Replay Using the I/O Condition Tool
The I/O Condition Tool specifies the execution file of the I/O Condition ex-
pressions specified in the [Settings] window in advance and monitors the
changes of the I/O memory areas set by the condition expressions of the I/O
Condition expressions, outputting when the conditions hold.
The I/O Condition Tool operates independently of the Debugger.
Computer
CX-Programmer
Debugger
I/O Condition Tool
FinsGateway
Virtual Communications Unit
CPU
Unit
Simulator
Communi-
cations Unit
To Next Page
