3-7 System Status Setting Window
3-7-1 System Status Setting Window
The [System Status Setting] window performs PLC model selection, the
Ladder Engine status display, cycle time display, UM set/display, network
communications set, Serial communications set, and others.
Transition of System Status Setting
Window
System Status Setting
(Outline display mode)
(Detail display mode)
Setting
PLC selection
PLC setting wizard
PLC unit registration
Network communications
setting
Network communi-
cations registration
Serial communications
setting
Serial port setting
Time-related PLC opera-
tion settin
g
UM setting
PLC operation setting
Messages
Alarm
