1-5-4 Monitor the Status
Objective Menu or Button to select
Display messages System Status | Message Display
Display alarms System Status | Alarm Display
Display cycle time details System Status | Detail
Display each status of the task Debug Console | Task Control
1-5-5 Set Serial Communications Settings
Objective Menu or Button to select
Set Serial Communications set-
tings
System Status | Set | Double-click the port used for Serial Com-
munications.
Disable Serial Communications
commands
In the above operation, set [− (Non)] to the Communications Set-
tings. (default)
Display the content of output by the
Serial Communications commands
In the above operation, set [Message] to the Communications Set-
tings.
Use an actual RS-232C port on the
computer for Serial Communica-
tions
In the above operation, set [Actual Communications] to the Com-
munications Settings.
1-5-6 Set Network Communications Parameters
Objective Menu or Button to select
Set network communications pa-
rameters
System Status | Set | Double-click the unit used for network com-
munications
Change the node number of the
network communications unit
In the above operation, change the value of FINS node address.
Disable network communications
commands
In the above operation, set [− (Non)] to the Communications Set-
tings. (default)
Display the content of output by
network communications com-
mands
In the above operation, set [Message] to the Communications Set-
tings.
Issue a network communications
command to the designated node
in the computer
In the above operation, set [Local] to the Communications Settings.
1-5-7 Execute Virtual External Input
Objective Menu or Button to select
Set a program area for debugging System Status | Set | UM Setting
Invoke data for data replay from a
file
Debug Console | Replay Menu | Data Replay
Set a command log Debug Console | Replay Menu | Command Log | set
Start a command log Debug Console | Replay Menu | Command Log | Start
Exit a command log Debug Console | Replay Menu | Command Log | Stop
Display command log data Debug Console | Replay Menu | Command Log | View Log
Set I/O Condition Debug Console | Replay Menu | I/O Condition | File Menu | Set
Execute I/O Condition Debug Console | Replay Menu | I/O Condition | Start
